| Low Power Monopole | |||||||||
| Model | output | Voltage （V）MIN |
Voltage （V）MAX |
Reverse voltage Protect（V） |
Magnetic working point （Gs） |
Magnetic release point (Gs) |
Working temperature （℃） |
Packaging form | |
 |
AH465 | Push-pull output | 2.5 | 5.5 | -0.3 | 35 | 25 | -40 to 85 | SOT23 TO92S |
| Low power bipolar | |||||||||
| Model | output | Voltage （V）MIN |
Voltage （V）MAX |
Reverse voltage Protect（V） |
Magnetic working point （Gs） |
Magnetic release point (Gs) |
Working temperature （℃） |
Packaging form | |
|
AH468 | Pus-pull output | 2.7 | 5.5 | 6 | 25 | -25 | -40~85 | SOT23 TO92S |
|
AH469 | push-pull output | 2.7 | 5.5 | 6 | 25 | -25 | -40~85 | SOT23 TO92S |
| Low Power Full Pole | |||||||||
| Model | output | Voltage （V）MIN |
Voltage （V）MAX |
Reverse voltage Protect（V） |
Magnetic working point （Gs） |
Magnetic release point (Gs) |
Working temperature （℃） |
Packaging form | |
|
AH462 | Push-pull output | 2.5 | 5.5 | -0.3 | 35 | 25 | - 40 to 85 | SOT23 TO92S |
|
AH463 | Push-pull output | 2.5 | 5.5 | -0.3 | 17 | 12 | -40 to 85 | SOT23 TO92S |
|
AH464 | Push-pull output | 2.5 | 5.5 | -0.3 | 30 | 20 | -40 to 85 | SOT23 TO92S |
|
AH466 | Push-pull output | 2.5 | 5.5 | -0.3 | 30 | 20 | -40~85 | SOT23 TO92S |
